68RFE stage 3

68RFE Street Sweeper Transmission

The Street Sweeper 68RFE is designed exactly how it sounds—built for trucks that are driven daily but abused on the weekends. Developed with the perfect balance of street manners and race-inspired durability, this transmission is ideal for owners who want to turn it up without giving up drivability.

The Street Sweeper is capable of handling a wide range of performance upgrades, including injector upgrades, second-gen swaps, aggressive tuning, and spirited street use, while still remaining reliable for daily operation. This unit bridges the gap between a mild build and a full competition transmission.

Transmission tuning is required to ensure proper operation, clutch life, and long-term reliability.

Features & Upgrades

• Bonded pistons for improved durability and sealing

• BorgWarner friction materials

• Brand-new solenoid assembly

• Complete overhaul kit

• New OEM speed sensors and line-pressure transducer

• Billet triple-disc torque converter

• Torrington bearing kit

• All new bushings throughout

• Deep Transmission Pan

• Billet input shaft

• Upgraded OE sprag

• Billet spin-on filter adapter

• TDP Pro Shift valve body

• Sonnax overdrive drum

• Billet 2C piston

• Billet 4C snap ring retainer

• Billet flexplate

• Valve body fully vacuum-tested; any valve that fails testing is oversized using Sonnax components

Tuning & Calibration Requirements

• TCM calibration must be data-logged and approved by Thompson Diesel Performance after installation

• If tuning parameters or guidance are needed, please reach out to us prior to or during tuning

• Failure to submit data logs for approval may result in denied warranty coverage

Tire Size & Gear Ratio Requirement

• Tire size must correctly match the axle gear ratio per the approved gear ratio chart

• Incorrect tire size paired with an improper gear ratio will result in immediate warranty void

• Proper tire-to-gear matching is critical for shift timing, clutch load, and overall transmission longevity

Warranty Information

• 2-Year Unlimited Mileage Warranty

• Warranty coverage is contingent upon:

  • Approved TCM calibration

  • Proper tire size and axle gear ratio match

  • Proper installation and maintenance

Availability

No current wait time on 68RFE units

Shipping

Shipping is not included in the listed price. Shipping options are available upon request or at checkout.
